Conformal Coating Surface Preparation Hub

Cleaning, contamination control, adhesion preparation and pre-coating process stability for PCB coating

This hub focuses on preparing PCB assemblies so that conformal coating can wet, adhere and remain reliable in production.

Surface preparation includes more than cleaning. Drying, contamination control, handling discipline, material condition, surface energy, storage and the time between preparation and coating can all influence the finished coating.

Many coating defects are symptoms of an earlier preparation problem. Flux residues, cleaning chemistry, fingerprints, silicone transfer, retained moisture, poor rinsing, low-energy surfaces or re-contamination after cleaning can all create coating failures even when the coating material and application equipment are correct.

Use this hub to understand the core preparation controls and then follow the supporting Bulletins where apparently clean or dry assemblies still fail during coating.

Conformal coating surface preparation process infographic showing cleaning, activation, handling, verification and coating stages

Surface preparation extends from cleaning and drying through handling, activation and final verification immediately before conformal coating.

Where Are You in the Preparation Process?

Preparation Failures & Supporting Guidance

A board can look clean, dry and ready for coating while still carrying hidden preparation risks. These supporting Bulletins show where failures commonly enter the process.

Moisture Can Remain After Cleaning

Residual moisture can remain beneath low-standoff components, inside connectors, in narrow gaps or within hygroscopic residues even when the assembly appears dry. Once coating is applied, that moisture can become trapped and contribute to white residues, bubbles, adhesion loss, corrosion or electrical leakage.

Bulletin: Moisture Trapped Before Conformal Coating โ†—

Visually Clean Does Not Mean Coating-Ready

Thin films of cleaning chemistry, flux activators, ionic residues, oils or other contamination may be invisible under normal inspection while still changing wetting, adhesion or long-term reliability.

Bulletin: Boards Look Clean but Still Fail Conformal Coating โ†—

Handling Can Re-Contaminate a Cleaned PCB

Cleaning only controls the surface at one point in time. Fingerprints, gloves, packaging, inspection, masking and rework can introduce oils, salts or other contamination immediately before coating.

Bulletin: Fingerprints and Handling Contamination Before Conformal Coating โ†—

Silicone and Masking Materials Can Contaminate the Surface

Silicone oils, release agents, unsuitable masking materials and contamination transferred from tools or elastomers can create highly localised low-surface-energy areas. These commonly appear later as de-wetting, fisheyes, craters or local adhesion loss.

Browse Cleaning, Contamination & Surface Bulletins โ†—

Small Cleaning-Process Changes Can Create New Defects

A change in cleaning chemistry, concentration, wash settings, rinse quality, drying time, board loading or maintenance can alter the real surface condition even when the cleaning process still appears operational.

Bulletin: Cleaning Process Changes Causing New Conformal Coating Defects โ†—

Cleaning Does Not Guarantee Correct Wetting

A cleaned assembly may still reject coating if residues remain, surface energy is low, cleaning chemistry has been redistributed or contamination has been introduced after cleaning.

Bulletin: Common Causes of De-Wetting After Cleaning โ†—

Surface Preparation & Cleanliness

A coating can only interact with the surface condition that actually reaches the coating station. Cleaning is therefore one element of preparation rather than the complete preparation process.

  • Identify flux residues, oils, dust, fingerprints, silicone and process chemicals that may affect coating.
  • Define the required cleanliness condition for the assembly and coating chemistry.
  • Ensure rinsing removes cleaning chemistry rather than redistributing it.
  • Dry the assembly sufficiently before coating, particularly beneath components and within restricted geometry.
  • Protect cleaned assemblies from re-contamination during storage, masking, inspection and movement.
  • Verify preparation against coating wetting, adhesion and product reliability requirements.

โ†‘ Back to Index ยท Read Surface Preparation Guide โ†—

Plasma Cleaning & Surface Activation

Plasma treatment can remove some surface contamination and increase surface energy, making it useful where conventional cleaning alone does not provide the required wetting or adhesion.

  • Identify whether the problem is contamination, low surface energy or another adhesion mechanism before adding plasma.
  • Validate plasma chemistry, power, exposure time and treatment parameters against the actual substrate.
  • Control the delay between plasma treatment and coating because activated surfaces can change with time.
  • Ensure plasma does not damage sensitive polymers, components or surface finishes.
  • Use plasma as a controlled preparation step rather than as compensation for an unstable cleaning process.

โ†‘ Back to Index ยท Read Plasma Cleaning Guide โ†—

De-Wetting & Poor Wetting

De-wetting occurs when the liquid coating cannot form and maintain a stable film over the surface. The visible defect appears during coating, but the root cause is often already present before application begins.

  • Check for silicone, fingerprints, oils, flux residues and cleaning chemistry.
  • Review whether the assembly was genuinely dry before coating.
  • Investigate low-surface-energy materials, solder-mask variation and component materials.
  • Review handling, masking and rework steps for re-contamination after cleaning.
  • Separate surface-condition problems from viscosity, atomisation or application-equipment problems.

โ†‘ Back to Index ยท Read De-Wetting Guide โ†—

Corrosion & Ionic Contamination

Conformal coating does not neutralise ionic contamination trapped beneath the film. When contamination, moisture and electrical bias combine, corrosion, leakage current or electrochemical migration can occur beneath an apparently intact coating.

  • Control ionic residues before coating rather than relying on the coating as compensation.
  • Review flux chemistry, rinse effectiveness and cleaning-process stability.
  • Consider contamination trapped beneath components or within difficult-to-clean geometry.
  • Ensure assemblies are properly dried after aqueous cleaning.
  • Link cleanliness requirements to the actual voltage, humidity and reliability risk of the finished product.

โ†‘ Back to Index ยท Read Corrosion & Ionic Contamination Guide โ†—

Surface Preparation & Process Control

A reliable surface-preparation system controls the complete route from cleaning through coating rather than treating cleaning as a single isolated operation.

  • Define cleaning chemistry, concentration, wash and rinse conditions.
  • Control drying time and conditions after cleaning.
  • Define how cleaned boards are handled, stored and transported.
  • Control gloves, tools, masking materials and work surfaces that contact cleaned assemblies.
  • Set maximum time limits between cleaning, activation and coating where required.
  • Record process changes because apparently small cleaning changes may alter coating performance.
  • Define inspection or verification criteria before release to coating.

โ†‘ Back to Index ยท Read Process Control Guide โ†—

Connect Surface Preparation to the Wider Coating Process

Preparation establishes the surface condition; the application and inspection processes must then preserve and verify it.
